RAY MONTAJ HDR SERİSİ
- Universal AC giriş 85-264 VAC
- Ultra ince dizayn
- Korumalar: Kısa devre, aşırı yük, aşırı voltaj
- Çalışma sıcaklık aralığı :-30 ~ +70 °C
- DIN Ray montajı, TS35/7.5 yada 15
- DC Çıkış voltajı ayarlanabilir
- Serbest hava akışı soğutmalı
- İzolasyon sınıf II
- LED çıkış durum göstergesi
- %100 tam yük testi
- 2 yıl garanti
HDR-15-12 Giriş 85-264V AC-120-370V DC / Çıkış 12V DC / 1,25A Plastik Kasa Güç Kaynağı
| MODEL | GİRİŞ | ÇIKIŞ | EBATLAR | |
|---|---|---|---|---|
| 15W HDR SERİSİ | ||||
| HDR-15-5 | 85-264VAC 120-370VDC | 5VDC | 2.4A | 17.5x90x54.5 mm |
| HDR-15-12 | 85-264VAC 120-370VDC | 12VDC | 1.25A | 17.5x90x54.5 mm |
| HDR-15-15 | 85-264VAC 120-370VDC | 15VDC | 1A | 17.5x90x54.5 mm |
| HDR-15-24 | 85-264VAC 120-370VDC | 24VDC | 0.63A | 17.5x90x54.5 mm |
| HDR-15-48 | 85-264VAC 120-370VDC | 48VDC | 0.32A | 17.5x90x54.5 mm |
| 30W HDR SERİSİ | ||||
| HDR-30-5 | 85-264VAC 120-370VDC | 5VDC | 3A | 35x90x54.5 mm |
| HDR-30-12 | 85-264VAC 120-370VDC | 12VDC | 2A | 35x90x54.5 mm |
| HDR-30-15 | 85-264VAC 120-370VDC | 15VDC | 2A | 35x90x54.5 mm |
| HDR-30-24 | 85-264VAC 120-370VDC | 24VDC | 1.5A | 35x90x54.5 mm |
| HDR-30-48 | 85-264VAC 120-370VDC | 48VDC | 0.75A | 35x90x54.5 mm |
| 60W HDR SERİSİ | ||||
| HDR-60-5 | 85-264VAC 120-370VDC | 5VDC | 6.5A | 52.5x90x54.5 mm |
| HDR-60-12 | 85-264VAC 120-370VDC | 12VDC | 4.5A | 52.5x90x54.5 mm |
| HDR-60-15 | 85-264VAC 120-370VDC | 15VDC | 4A | 52.5x90x54.5 mm |
| HDR-60-24 | 85-264VAC 120-370VDC | 24VDC | 2.5A | 52.5x90x54.5 mm |
| HDR-60-48 | 85-264VAC 120-370VDC | 48VDC | 1.25A | 52.5x90x54.5 mm |
| 100W HDR SERİSİ | ||||
| HDR-100-12 | 85-264VAC 120-370VDC | 12VDC | 7.1A | 75x90x54.5 mm |
| HDR-100-15 | 85-264VAC 120-370VDC | 15VDC | 6.13A | 75x90x54.5 mm |
| HDR-100-24 | 85-264VAC 120-370VDC | 24VDC | 3.83A | 75x90x54.5 mm |
| HDR-100-48 | 85-264VAC 120-370VDC | 48VDC | 1.92A | 75x90x54.5 mm |
| 150W HDR SERİSİ | ||||
| HDR-150-12 | 85-264VAC 120-370VDC | 12VDC | 11.3A | 105x90x54.5 mm |
| HDR-150-15 | 85-264VAC 120-370VDC | 15VDC | 9.5A | 105x90x54.5 mm |
| HDR-150-24 | 85-264VAC 120-370VDC | 24VDC | 6.25A | 105x90x54.5 mm |
| HDR-150-48 | 85-264VAC 120-370VDC | 48VDC | 3.2A | 105x90x54.5 mm |
- Ebatlar (Boy x En x Yükseklik) mm.
