757-284/000-010 M12, 8-way, 4-pole, 10m cable OPur, halogen free with LED

Brand
Stock code
757-284/000-010
*starting from 14,45 USD!
%50 Discount
130,01 USD + VAT
312,02 USD
Transfer
156,01 USD
Contact us for purchases over 200kg and 15.000 EURO
Details
technical data
R ON (max.) 0.01Ω
Supply voltage DC 10 ... 30 V; Rated voltage: 32V ~ eff.
Current carrying capacity of signal connections 2 A
Current carrying capacity of the supply connections 9 a
Nominal value of electrical insulation 500V
Functionally separated potential groups Contact / Contact
Insulation resistance 1000
Signal characteristic PNP
Indicators LED (A) yellow: Signal status (1 x per contact); LED (U) green: Sensor / actuator box status
More
connection data
Connection technology: Inputs / Outputs 8 x M12 connectors, 4-pole, incl. PE
Connection technology: main cable 1 x fixed connection cable
cable length 10m
Stripping length 100mm / 3.94 inches
Colors of potential customers white, green, yellow, gray, pink, red, black, purple, green/yellow, brown, blue
Conductor cross section Cross section min (1): 0.34 mm²; Max. cross section 2: 1 mm²
More
Geometric Data
Width 60mm / 2.362 inches
Height 26mm / 1,024 inches
Depth 152mm / 5.984 inches
Mechanical Data
Mounting type screw slot
Material Data
Body material PA 66 (UL 94 V0); RAL 7035
halogen free Yes
Sheathed cable diameter 8.2mm
bending radius min. 10 x cable Ø
Material properties of connections Contact: CuSn, pre-nickeled and 0.8 µm gold plated; Grooved bush: Zn diecast nickel plated; Seal: Viton; Connection loops: 50
sheath material DURATION
Color of sheathed cable black
Planting Fully encapsulated with conformal coating (UL 94 V0)
More
Environmental Requirements
Surrounding air (operating) temperature -25… 80 °C
Ambient temperature (operation) moved -5… +80 °C
Ambient temperature (working) rest -40… +80 °C
Protection class IP68
Note on Protection Type 72 hours underwater at a depth of 1 m in accordance with EN 60529, fully locked with stoppers or protective caps
Pollution degree (5) 3 according to VDE 0110
vibration resistant acc. According to IEC 60068-2-6
Impact resistance acc. According to IEC 60068-2-27
More
Commercial Data
Packaging type from SAP BOX
Country of origin NIN-NIN
GTIN 4045454028473
Customs Tariff number 85366990990
